Touchscreen Metal Detector – Smart Contaminant Detection Solutions
ApplicationOur Smart Conveyor Metal Detector is widely used across multiple industries to detect and eliminate metal contaminants such as iron, copper, aluminum, and stainless steel. It is especially suitable for food products including bread, buns, dumplings, biscuits, and other baked or packaged goods. In addition, it serves the pharmaceutical, toy, textile, footwear, leather, chemical, and knitting industries by identifying and removing metallic impurities from products. This not only enhances product safety and quality but also helps businesses comply with industry standards and improve customer satisfaction.
Why Choose Redmark Industry?
1. Advanced Inspection Technology
The HY-990 is equipped with high-precision digital detection, a large LCD touchscreen, and customizable settings—delivered by us with expert setup and calibration.
2. Certified to International Standards
Redmark ensures the HY-990 complies with HACCP, GMP, FDA, and CAS—suitable for critical quality control applications in regulated industries.
3. Smart Product Learning
Redmark configures the SA-990 with intelligent self-learning features to adapt to various product effects and minimize false rejections.
4. Complete Technical Support
Redmark provides professional on-site training, commissioning, and after-sales service to ensure optimal performance of the HY-990 in your facility.
Features
-
High Detection Accuracy: Utilizes imported core components, advanced digital technology, and one-time molded detection coils for precise and stable metal detection.
-
Touch Screen Interface: User-friendly interface with an LCD display for quick setup and parameter adjustment.
-
Self-Learning Function: Automatically identifies and stores product characteristics to reduce false alarms caused by "product effects."
-
Multi-Frequency & Storage: Supports multiple frequencies with storage capacity of over 100 product test data.
-
Modular Design: Enables fast and easy maintenance or part replacement.
-
IP65 Waterproof Design: Built to withstand harsh environments with vibration and noise protection.
-
Flexible Rejection Methods: Options include flap lift, air blow, and swing arm mechanisms based on user needs.
- Food Grade Materials: Constructed with stainless steel and food-grade PU belts, complying with hygiene regulations.
Benefits
-
Detects ferrous and non-ferrous metals (including stainless steel), reducing contamination risks in food, pharmaceutical, and other industries.
-
Detailed data logging and real-time monitoring ensure consistent product quality and traceability.
-
Quick setup, easy operation, and minimal recalibration boost operational efficiency and reduce downtime.
-
Meets international food safety and pharmaceutical standards, supporting certifications and audits.
-
Ideal for use in food processing, pharmaceuticals, textiles, toys, footwear, chemicals, leather, and more.
Specification Smart Conveyor Metal Detector :
| Model | HY-990 | |||||||||
| Specifications | Standard | Customized | ||||||||
| Detection Width(mm) | 400 | 400- Customized size | ||||||||
| Detection Height(mm) | 80 | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 450 | |
| Detection Sensitivity | Fe(Φmm) | ≥0.8 | ≥0.8 | ≥0.8 | ≥0.8 | ≥1.0 | ≥1.5 | ≥1.8 | ≥1.8 | ≥2.5 |
| Non-Fe(Φmm) | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥1.2 | ≥1.8 | ≥2.0 | ≥2.0 | ≥3.0 | |
| 304Sus(Φmm) | ≥1.5 | ≥1.5 | ≥1.5 | ≥2.0 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.0 | ≥4.0 | |
| Sensitivity | 0-99 adjustable | |||||||||
| Product storage parameters | 100 kinds | |||||||||
| Product testing information storage | Detection alarm detailed information storage function, easy to monitor product quality | |||||||||
| Display and operation mode | Touch screen, touch operation mode | |||||||||
| Sidewall material | White imported PP material, (with third-party test report) | |||||||||
| Conveying direction | Facing the console from left to right | |||||||||
| Belt material | Food grade white belt PU material (with third party test report) | |||||||||
| Belt height from ground | 750+100mm | |||||||||
| Transfer speed | 5-28m/min (optional adjustable) | |||||||||
| Removal method | Steam blowing and rejection Flap lift Swing arm (optional) | |||||||||
| Waterproof level | IP65 | |||||||||
| Maximum load (single piece) | 25Kg | |||||||||
| Operating Environment Requirements | Adapt to temperature -15°-40° (no freezing, sharp temperature changes); adapt to temperature 30-85% RP (no condensation) | |||||||||
| Alarm method | When metal foreign objects are detected, it will automatically stop running, and the buzzer will alarm or reject it. | |||||||||
| Machine material | The whole rack is made of 304 stainless steel, in line with HACCP, GMP, FDA, CAS and other standards | |||||||||
| Mechanical dimension(mm) | 1330×850×950(L×W×H) | |||||||||
| Machine weight | About 135KG | |||||||||
| Motor | 120W | |||||||||
| Power | 158W | |||||||||
| Power supply | AC220V，50-60Hz | |||||||||
| Remarks: The above sensitivity parameters are the test results when the aircraft is empty without environmental interference. The actual application will be slightly different due to the use environment and the interference of the components of the detected object! | ||||||||||
Get in Touch with Redmark Industry Today
Proudly serving Malaysia and the wider Asian region, Redmark Industry provides trusted solutions like the Touch Screen Intelligent Metal Detector—designed to enhance product safety and quality across industries. Reach out now for more information or to request a customized quotation!
