RUT200 is a compact industrial cellular router designed to provide reliable connectivity in demanding industrial conditions prevalent in the automation, transportation, and manufacturing sectors. Featuring 4G LTE, Wi-Fi, and two Ethernet ports, it offers a seamless setup for primary and backup connectivity along with remote management capabilities. Its compatibility spans networks in Asia, CIS, the Middle East, Africa, and South America. With its industrial design, compact size, and versatile I/Os, the RUT200 is an ideal solution for mission-critical connectivity needs across manufacturing, automation, transportation, and other industrial scenarios that require robust connectivity in challenging environments.








Remote Management System (RMS)

Teltonika Networks Remote Management System is an all-in-one, user-friendly IoT platform providing an easy way to stay on top of your connected solution. It is a powerful software that allows remote access and management of all connected Teltonika Networks and third-party devices.



Teltonika Networks RMS has various available services that allow for extensive control and advanced analytics for compatible devices. There are 3 types of RMS Services:

• Management: Complete remote control over all connected Teltonika Networks compatible devices even without a public IP.
• Connect: Unified access system allowing to reach and control connected smart devices remotely with RMS.
• VPN: RMS VPN is the safest way to reach multiple endpoints remotely.

Note: All Teltonika devices including this RUT200 come with a free 30-day trial period for the RMS.



Security is the top priority for all Teltonika Networks products and the same applies to RMS. We use multiple measures to ensure a safe connection, including numerous security protocols and data encryption.

• Encrypted Communication: Keep your setup safe with encrypted channels to communicate with Teltonika Networks and third-party devices.
• Proprietary Protocol: Ensure the safety of your data transfer between router and server with the proprietary protocol.
• AWS Cloud Security: RMS is hosted on AWS, chosen for its robust security capabilities and tools.
• Teltonika ID: Use your biometrics for highly secure yet fast and easy authentication.



This is a great video from RFShop that explains the difference between industrial and consumer-grade routers:


Features


Hardware:

• Mobile:
  • 4G/LTE – Cat 4 up to 150 Mbps
  • 3G – Up to 42 Mbps
  • 2G – Up to 236.8 kbps
• CPU: Mediatek, 580 MHz, MIPS 24KEc
• Storage: 16 MB Flash
• Memory: 128 MB RAM
• Powering Option: 4pin power socket, 9-30 VDC
• SIM: 1 x External SIM holder (2FF)
• Antenna Connectors:
  • 2 x SMA for mobile
  • 1 x RP-SMA for WiFi
• Ethernet: 2 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 1 x LAN
• WiFi: IEEE 802.11b/g/n, Access point (AP), Station (STA)
• Inputs/Outputs on 4pin Socket:
  • 1 x Digital input
  • 1 x Digital open collector output
• Status LEDs:
  • 3 x Connection type
  • 5 x Signal strength
  • 2 x Ethernet
  • 1 x Power
• Operating Temperature: -40 °C to 75 °C
• Housing: Aluminium housing with DIN rail mounting option, plastic panels
• Dimensions: 83 x 25 x 74 mm (W x H x D)
• Weight: 125 g
