KOKENT ENTERPRISE SDN BHD
KOKENT ENTERPRISE SDN BHD 350878-W
Onesync Platinum + SSM
访客
商业性质:

提供者

相关分类:

雪兰莪,吉隆玻,Jalan Cheras - Grundfos CMBE10-54 Inverter Low Noise Home Water Pump Water Booster Pump

19-Jul-2021


Why Choose KOKENT ENTERPRISE?
We have more than 30 year of company operation and Water Pump Service Experience ! And not only for Water Pump ! We also Selling Hardware and Machinery ( Power tools, Hydraulic equipment, Workshop Equipment, and Pump Equipment etc) Good service and price
Slogan {We always hope our customer can buy happy not just product}''

1) Kokent Enterprise Sdn Bhd (Easy to search in Waze , Google Map)
    No. 522, Jln Cheras, Batu 3 1/4, 56100 Kuala Lumpur, Wilayah Persekutuan Kuala Lumpur

2) Grundfos Authorized Dealer, 100% Original Product !

3) Free consultation on installation and service repair !

4) Repair spare part ready stock !




Grundfos CMBE 10-54 is year 2021 grundfos’s latest inverter pump. This model is to replace UNI E CM10-2 (old model)

Grunfos CMBE10-54 is a 2HP pump with variable speed. So you dont have to worry that the HorsePower is too strong and might burst your pipe as the water pressure is adjustable. When one person turns on the tap, the pump will go low speed and when more people are using water, the pump will automatically speed up to maintain the 2.5bar pressure. Unlike regular pumps, when u turn on the water the pump  operate at full speed and could go upto 5 bars depending on the spec of the pump, the more you use, the more pressure drops. Since CMBE 10-54 runs on low speed when usage is low, noise and vibration will be lesser. Regular pumps even at low usage, the pump will go on full speed, similar to a ceiling fan, at high speed it is noisy and high vibration.

When you turn off the water CMBE10-54 will slowly stop and the pressure tank above acts like an absorber to reduce water hammering issue. When you turn off the water and you hear a loud banging sound, that is water hammering. As water is travelling at a high speed in the pipeline and when u suddenly turn off the water it is like a car travelling at high speed and suddenly crash into a wall, the momentum will cause a loud banging sound. As CMBE10-54 is a variable speed pump, when usage is low, it will go low speed and hence less momentum = less noise, moreover with the pressure tank it helps to absorb some of the momentum as well.

Grundfos CMBE 10-54 best price, Grundfos CMBE 10-54 promotion, Grundfos CMBE 10-54 sale, Grundfos CMBE 10-54 review, CMBE 10-54 water pump. If you find somewhere else cheaper, show us and we will beat the price if it is legit.

Grundfos CMBE 10-54 comes with dry run protection function while regular pressure tank pumps do not have this feature. Dry run protections means, if there is no water supply (pipe is dry) the pump will automatically stop, hence it will not overheat. Compared to a regular pressure tank pump, the pump will only stop when the build up water pressure hits cut off point such as 5 bar, if there is no water, the pump could not build up pressure, hence the pump will keep running non-stop and this will damage the pump.

So for old houses with old pipes, Grundfos CMBE 10-54 is the best pump that you can get.

SPECIFICATIONS
Size : 490L x 232W x 506H mm
Connection Size : 1 1/2″ inlet & 1 1/2″outlet
Electricity Consumption : 1500watt
Horsepower (HP) : 2.0hp
Rated Flow : 12.3 m³/h
Rated head : 25.1m
Warranty :
3 years warranty + Free One on site service by Grundfos Authorized Service Team

Features & Benefits
–  Product Certified by SIRIM
– Quiet Operation <54dB(A)
– 3 years warranty + Free one One site service by Grundfos Authorized Service Team
– Energy Saving
– Constant pressure driven by INVERTER
– Quality Assurance
– Longer life span
– Eliminate water hammering


Technical

Pump speed on which pump data are based 3868 rpm
Rated flow 12.3 m³/h
Rated head 25.1 m
Impellers 2
Primary shaft seal AQQE
Approvals and markings CE,CULUS
Curve tolerance ISO9906:2012 3B
Model A
Return valve YES
Start pressure Integrated Frequency converter

Materials

Pump housing Stainless steel
  DIN W.-Nr. 1.4301
  AISI 304
Impeller Stainless steel
  DIN W.-Nr. 1.4301
  AISI 304
Rubber EPDM

Installation

Maximum ambient temperature 50 °C
Flange standard INTERNAL NPT THREAD
Pump inlet NPT 1 1/2
Pump outlet NPT 1 1/2


Liquid

Pumped liquid Water
Liquid temperature range 0 .. 60 °C
Selected liquid temperature 20 °C
Density 998.2 kg/m³

Electrical data

Rated power - P2 1.5 kW
Mains frequency 50 / 60 Hz
Rated voltage 1 x 200-240 V
Maximum current consumption 9.10-7.60 A
p max system 10 bar
Rated speed 360-4000 rpm
Enclosure class (IEC 34-5) IP55
Insulation class (IEC 85) F
Type of cable plug NONE
Mains cable NO CABLE m

Tank

Tank volume 2 l

Others

Net weight 24 kg
Gross weight 34 kg
Config. file no 98442578

Features & Benefits of Grundfos CMBE10-54 water pump:

◊ Longer life - Major pump components are manufactured from corrosion and wear resistant stainless steel.
◊ Quiet Operation - Both pump and motor are designed for low operation noise <54dB(A) to provide a comfortable environment.
◊ Quality Assurance - Each CMBE10-54 is factory assembled and tested before delivery.
◊ Product certified by SIRIM
◊ Energy saving
◊ Constant pressure driven by INVERTER
◊ Eliminates water hammering
◊ 3 years warranty
◊ Space saving
◊ Easy installation, setting and operation
◊ Built-in overload protection with Auto restart on power failure


CONDITIONS OF WARRANTY

1. Grundfos will grant a 2 year warranty on the product against manufacturing defects commencing from the date of purchase. If the date of purchase is more than 60 days from the date of delivery, then it is necessary to attach a photostat copy of your purchase receipt to this warranty card and return them to Grundfos.

2. The warranty only comes into force if the date of purchase is confirmed by the dealer's stamp on the warranty card, and if the card is sent to Grundfos office within 7 days from the date of purchase.

3. Within the warranty period, Grundfos shall carry out the repair or replacing of parts at Grundfos' option, ex-factory or ex-authorised Grundfos Service Centre, any product of Grundfos' manufacture.

4. Grundfos will not be liable for any costs of removal, installation, transportation, or any charges which arise in connection with this warranty claim.

5. Grundfos will not be liable for any replacement of parts caused by normal wear & tear, damage caused by dry running, cavitation, unsuitable operating condition, unfavourable electric supply, mishandling, flooding, lightning, unauthorised alteration or repair, misapplication and product which is installed not in accordance to Grundfos printed installation and operating instructions.

6. To obtain warranty claim, the defective product must be returned to the Grundfos Service Centre with freight prepaid; warranty card/receipt supporting the claim must be included. Failure to present warranty card / receipt shall render the warranty claim invalid.

NOTE: The Warranty Card (Customer Copy) and original purchase document(s) must be produced for inspection when warranty service is requested. Any alteration or amendment to this certificate will render the warranty void. This warranty card is irreplaceable in the event of loss. The decision of Grundfoss in relation to any claims or dispute over the warranty is final.

*No warranty will be given if the above conditions are not met with completely.
