Technical Data:
|
Basic function |
Range |
Basic Accuracy |
|
Contact rotation speed |
0.5～19,999RPM (r/min) |
± (0.05%+1 digit) |
|
Contact line speed (metric) |
0.05～1999.9m/min (m/Min) |
± (0.05%+1 digit) |
|
Contact line speed (Imperial) |
0.2～6560ft/min (inch/min) |
± (0.05%+1 digit) |
Special Function:
|
Model |
DT-6235B |
|
Measuring way |
Contacted |
|
Resolution |
Rotation speed: 0.1RPM (r/min) (0.5～999.9RPM) 1RPM (r/min) (over 1000RPM) Surface speed: 0.01m/min (0.05～99.99m/min) 0.1m/min (over 100m/min) 0.1ft/min (0.1～999.9ft/min) 1ft/min (over 1000ft/min) |
|
Sampling time |
0. 8 (over 60RPM) |
|
Range selection |
Auto switch |
|
Power Consumption |
Max. 45mA |
|
Memory |
Auto memory Max./Min. last value and auto store 96teams data |
|
Time Base |
6MHz Quartz crystal |
|
Accuracy of time base |
10×10-6 (0℃～50℃) |
|
Battery |
4X1.5V AA Size Battery or to external DC 6V |
|
Max. display |
99999 |
|
LCD size |
5digits, 18mm high |
