IMITOS 12V LED Strip Light 50W SMD5050 5M
Brighten up your indoor spaces with the high-density IMITOS SMD LED Strip Light 50W (Model: SMD5050-120P 12V). Operating on a safe DC12V 5A system, this premium 5-meter strip features a massive 600 LEDs to deliver seamless, dot-free linear illumination. Available in Warm White (3000K), Cool White (4000K), and vibrant Blue, its IP20 rating makes it the ultimate choice for modern plaster ceiling troughs, cove lighting, cabinet backlighting, and commercial ID fit-outs in Malaysia.
Full Professional Description:
Transform ordinary architectural spaces into stunning, modern environments with the professional-grade IMITOS SMD LED Strip Light 50W. Specially engineered for interior designers, electrical contractors, and DIY enthusiasts across Malaysia, this high-performance lighting solution delivers smooth, high-intensity linear light without the unpleasant "spotting" effect common in low-quality alternatives.
Why Choose the IMITOS 12V 50W LED Strip?
- Ultra-Bright, Even Illumination: Equipped with 120 premium SMD5050 chips per meter, this 50W strip eliminates dark spots. When paired with a diffuser, it creates a sleek, unbroken ribbon of light that elevates the aesthetic value of any luxury residential or commercial property.
- Safe and Stable DC12V Low Voltage: Operating on a low-voltage DC12V 5A infrastructure, the IMITOS strip light generates minimal heat. This makes it incredibly safe to handle during installation and significantly extends the lifespan of the LEDs.
- Limitless Design Flexibility: The flexible PCB allows you to easily bend, curve, and trace shapes along complex architectural layouts. Whether you are illuminating a geometric dropped ceiling box, creating a floating bed effect, or accentuating under-cabinet countertops, IMITOS adapts to your creativity.
- Tailored Indoors Protection (IP20): With its open-air IP20 non-waterproof design, this LED strip prioritizes maximum heat dissipation directly from the chips to the air. This structure keeps the strip running cool, making it highly durable for enclosed indoor environments like wardrobes, display cases, and TV consoles.
Installation & Wiring Guide
- Ensure the mounting surface is clean, dry, and free of dust or grease.
- Measure and cut the strip only along the designated copper cut marks.
- Peel off the heavy-duty adhesive backing and press the strip firmly onto your surface (or aluminum profile).
- Connect the positive (+) and negative (-) wires to a DC12V 5A power supply.
- Turn on the mains power and enjoy your premium, architectural-grade illumination!
Specification:
-
Model: SMD5050-120P 12V
- Voltage: DC12V5A
- Wattage: 50W
- Meter: 5 Meter
- LED Qty: 600LED
- Colour Temperature: 3000K,4000K,BLUE
- IP Rating: IP20
Q1: Can I connect the IMITOS SMD5050 12V LED Strip directly to my home wall plug?
A: No, you cannot connect it directly to a standard 220V–240V Malaysian wall socket. This LED strip runs on safe, low-voltage DC12V. You must use a compatible DC12V 5A (or higher) power supply transformer to convert your home AC electricity to DC power, otherwise the strip will burn out instantly.
Q2: What is the difference between 3000K, 4000K, and Blue color options?
A: 3000K Warm White gives off a soft, cozy yellowish glow ideal for bedrooms and living rooms. 4000K Cool White provides a bright, crisp neutral white that mimics natural daylight, perfect for kitchens and workspaces. Blue offers a vibrant, modern colored accent light ideal for gaming setups, commercial bars, and unique feature walls.
Q3: Can this IMITOS 50W LED Strip Light be cut to short lengths?
A: Yes! The strip features dedicated copper cutting points spaced at regular intervals. You can safely cut the strip to your preferred length using a pair of scissors. Ensure you only cut exactly along the marked lines to avoid damaging the rest of the circuit.
Q4: Is the IMITOS SMD5050-120P waterproof for outdoor or bathroom use?
A: No, this specific model features an IP20 rating, which means it is non-waterproof. It is strictly designed for dry indoor applications. Do not use it outdoors, in bathrooms, or in areas exposed to heavy moisture or splashing water.
Q5: What does "120P" mean in the model specification?
A: "120P" stands for 120 pieces of LED chips per meter. Because this is a 5-meter roll, it packs a high density of 600 LEDs in total. High-density strips provide much smoother, more even lighting with significantly fewer dark gaps between the bulbs compared to standard 60-LED options.
Q6: What type of power supply driver do I need for this 5-meter strip?
A: Since the strip requires a voltage of DC12V and consumes 50W of power, you need a transformer that can output at least DC12V 5A (12V x 5A = 60W, leaving a safe 20% overhead buffer to ensure the longevity of your driver).
Q7: Can I dim the IMITOS 12V 50W LED Strip Light?
A: Yes, this LED strip is fully dimmable. However, the dimming capability depends entirely on the power supply and controller you use. To dim it, you must connect the strip to a dimmable 12V LED driver or install an external 12V inline LED dimmer controller.
Q8: Why is a 12V LED strip better than a 220V direct AC LED strip?
A: 12V low-voltage systems are significantly safer to handle, cut, and install because they carry no risk of dangerous electrical shocks. They also generate much less localized heat and have a significantly shorter cutting interval, allowing for high-precision architectural fitting.
Q9: Why is a 12V LED strip better than a 220V direct AC LED strip?
A: Yes, the back of the flexible PCB is equipped with a high-quality double-sided adhesive tape. This allows for quick, peel-and-stick mounting onto clean surfaces such as aluminum channels, wood, or smooth plaster.
Q10: Where is the best place to install this IMITOS LED strip for a luxury look?
A: The most popular applications in Malaysia include plaster ceiling cove troughs, under-cabinet lighting for modern dry kitchens, behind custom wall feature panels, inside wardrobes, and beneath retail display shelves to create high-end aesthetic value.
