SPECIFICATIONS

Item
Table size - 600 x 360 mm
Max.Table capacity - 250 kg
T-slot - 100 x 18 x 3
Spindle speed - 8000rpm (OPT. 10000 / 12000 / 15000 rpm)
Motor (Mitsubishi / Fanuc) - 7.5 hp
Controller (Mitsubishi / Fanuc) - M70/M80 or 0i-MF
Power - 10 kva
Weight - 2800 kg

Travel
Max.X axis travel - 510 mm
Max.Y axis travel - 400 mm
Max.Z axis travel - 450 mm
Spindle nose to table - 200-650 mm

ATC System
Tool Q'ty - Arm type 20T
Max.Tool diameter - 65 mm
Max.Tool length - 200 mm
Max.Tool weight - 3 kg
Tool shank - BT30

Feed Rate
X rapid travel - 48 linear
Y rapid travel - 48 linear
Z rapid travel - 48 linear
Cutting feed rate - 1-1000 mm/min
