Mounting Type Through Hole
Coil Voltage 15VDC
Contact Form DPST-NO (2 Form A)
Contact Rating (Current) 1 A
Switching Voltage 200VDC - Max
Coil Current 7.5 mA
Coil Type Non Latching
Features -
Termination Style PC Pin
Seal Rating Sealed - Fully
Must Operate Voltage 10.5 VDC
Must Release Voltage 2.2 VDC
Operate Time 0.5 ms
Release Time 0.1 ms
Operating Temperature -20°C ~ 70°C
Contact Material -
Coil Resistance 2 kOhms
