ECCN (US) EAR99
DC Coil Voltage (V) 24
Coil Current (mA) 24
Coil Resistance (Ohm) 1K
Maximum Contact Resistance (mOhm) 150
Insulation Resistance (Ohm) 10T(Min)
Maximum Pick-Up Voltage 18VDC
Maximum AC Switching Voltage (V) 10K
Maximum DC Switching Voltage (V) 10K
Maximum Switching Current (A) 3
Minimum Dropout Voltage 2VDC
Maximum Carry Current (A) 5
Isolation Across Contacts 15KVDC(Min)
Isolation Across Coil and Contacts 15KVDC(Min)
Maximum Switching Power 50W
Operate Time (ms) 3
Release Time (ms) 1.5
LED Indicator No
Push to Test Button No
Mounting Through Hole
Relay Construction Non-Latching
Minimum Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 70
