MAG BG856
Spring-Free Barrier Gate
| Model | Arm Type | Pass Through Time | Arm Swing Out |
| BG856 |
Standard telescopic arm Spring-free up to 4.5m Built in power supply for traffic detector |
Less than 2.5 sec | Yes |
| BG856E UPGRADE |
Extra long telescopic arm 5.5mm spring to support additional 4.5m to 6m length Spring Crank |
Less than 3.5 sec | No |
| BG856F UPGRADE | Folding Arm 90° Spring-free up to 4m Folding Arm Bracket, Folding Arm Support Set | 1.8 sec | No |
BG856 barrier gate is typically installed at the entrance along with an access control reader
to restrict unauthorized vehicle access.It is able to support multiple length within 4.5m telescopic arm
with swing out function, without any supporting spring. With a pass-through time of 2.5s or lesser,
BG856 is the most cost-effective among our barrier gates.
Springs in barrier gate will be weakened due to fatigue over time, requiring routine maintenance.
The spring-free BG856, powered by the robust MAG RedSpeed Motor with automatic MultiSpeed
ensures that the barrier gate work longer and harder for you.
Slim and affordable
BG856 minimalist slim profile enhances the visual of your guardhouse vehicle entrance.
The spring-free motor is optimized to be very affordable for medium traffic site.
Proven recognition
MAG are the only guard house access security system that has won DOUBLE award in Malaysia.
Winning the Malaysia Book of Record and BrandLaureate award is a strong recognition
from our customer on our fast service, design innovation and product quality.
Click here to learn how our award-winning No-Clone-No-Shake system can help enhance your guard house security.
What sets BG856 apart?
Following are some technology highlights for BG856.
Lower cost to replace an arm
It is a common arm broken after hit by a car. A 4.5m arm is too long and against JPJ government on the road
regulation to be transported with a normal car or van.
Our telescopic arm can be retracted shorter to fit into a normal car or van.
This helps you save money and hassle to rent an expensive big truck just to transport 1 replacement arm.
Up and running most of the time
The intruder might take advantage of the security loophole when the gate is down for a long time.
MAG authorized dealers can leverage our wealth of experience in our support team,
online knowledge base and warranty service to ensure any technical issue can be resolved faster.
No more worries about language problems with an overseas supplier.
Fix your damaged gate faster
During a malfunction, your site will be exposed to security threats
if you have to wait a long time for spare parts to arrive from overseas.
MAG offers full spare parts and repairing service locally at an affordable price to ensure
your gate can resume operation in the shortest time possible.
Maximize the full benefit of your investment
Mix and match different brands might sacrifice certain functions due to incompatibility.
Contacting different suppliers will slow down troubleshooting time. MAG offers a complete solution of the gate,
access control, CCTV and integrated security software so that you can enjoy full features with faster technical
support from us as a single supplier through our authorized dealers.
Enjoy the feeling of making the right decision
About 20,000 MAG barrier gate has been successfully installed all over Malaysia and oversea country.
MAG barrier gate proven quality with affordable price is well accepted by happy customers worldwide.
BG856 with improved performance while maintaining affordability shall automate
your vehicle access security with ease.
Site implementation:
Start enhancing your guard house to look more premium with our beautiful gate at affordable price \
with rock solid after sales service today. Click here to contact us now for more information.
|
Specification:
|
|
|
Motor
|
MAG RedSpeed DC Brushless Motor |
| Max. Torque (arm shaft) | 290 Nm |
| Max. Speed (motor) | 650 rpm |
| Max. Power | 180W |
| Operating Temperature | -35° to 70 °C |
| Power Supply Input | 220V ± 10% AC, 50/60Hz |
| DC Power Supply 24V 10A | |
| Relative Humidity | < 80 %, non-condensing |
| Pass Through Time | 1.8 to 4s, based on arm length |
| Arm Type and Length | Telescopic arm up to 4.5m |
| 90° Folding arm up to 4m | |
| IP Rating | IP54 |
| Mean Time Before Failure (MTBF) | 3.5 million times |
|
Ordering Info:
|
|||
|
Model
|
Arm Type | Pass Through Time | Arm Swing Out |
| BG856 | Standard telescopic arm Spring-free up to 4.5m | Less than | Yes |
| 2.5 sec | |||
| UPGRADE BG856E | Extra long telescopic arm | Less than 3.5 sec | No |
| 5.5mm spring to support | |||
| additional 4.5m to 6m length | |||
| Spring Crank | |||
| UPGRADE BG856F | Folding Arm 90° | 1.8 sec | No |
| Spring-free up to 4m | |||
| Folding Arm Bracket, | |||
| Folding Arm Support Set |
