Coherent Finisar FTLF8519P3BNL FTLF8519P3BTL
2.125 Gb/s RoHS Compliant Short-Wavelength SFP Transceiver
.png){kind=logo}
PRODUCT FEATURES
• Up to 2.125 Gb/s bi-directional data links
• Hot-pluggable SFP footprint
• Built-in digital diagnostic functions
• 850nm Oxide VCSEL laser transmitter
• Duplex LC connector
• RoHS Compliant and Lead-Free
• Up to 550m on 50/125μm MMF,
300m on 62.5/125μm MMF
• Metal enclosure, for lower EMI
• Single 3.3V power supply
• <500mW power dissipation
• Industrial operating temperature range: -40°C to 85°C
APPLICATIONS
• 1.25 Gb/s 1000Base-SX Ethernet
• Dual Rate 1.063/2.125 Gb/s Fibre Channel
• Wireless – CPRI, OBSAI, LTE
