AP-AB1108 Electric-Shock-Proof High Efficiency AC Ion Bar
The AP-AB1108 is a compact bar-type AC ionizer designed for rapid static removal. It utilizes high-voltage AC ionization and optional compressed air assistance for enhanced static neutralization across various industrial applications.
Key Features
- Elegant compact rod structure
- High-voltage micro-current safety design
- Anti-electric-shock protection
- Tungsten discharge electrodes
- Supports airflow-assisted ion delivery
Technical Specifications
| Working Voltage | AC 5600V (<1m) / AC 7000V (≥1m) |
| Power | 20W |
| Discharge Range | 150–3000mm (L), 300mm (W), up to 600mm (H) |
| Installation Distance | 100–600mm |
| Discharge Speed | ≤ 2.5s @ 300mm, 0.3MPa |
| Emitter | Tungsten |
| Air Pressure | ≤ 0.6MPa |
| Connector | Φ8 – G1/8 |
| Operating Temp | 0–50°C |
