PHILIPS PROFESSIONAL LAMP FLUORESCENT MASTER PL-C 18W/827/830/840/865 2P 1CT/5X10CC
-
927905782701 - MASTER PL-C 18W/827/2P 1CT/5X10CC
-
927905783001 - MASTER PL-C 18W/830/2P 1CT/5X10CC
-
927905784001 - MASTER PL-C 18W/840/2P 1CT/5X10CC
-
927905786502 - MASTER PL-C 18W/865/2P 1CT/5X10CC
MASTER PL-C 2 Pin
MASTER PL-C 18W/827/830/840/865 2P 1CT/5X10BOX
MASTER PL-C is an efficient medium-wattage compact fluorescent lamp, typically used in general downlights for retail, hospitality and office applications. The original Philips-invented bridge technology guarantees optimum performance in the application, enabling more light and higher efficacy than the bended technology. The 2-pin version is designed for operation on electromagnetic gear and is provided with a plug-in/pull-out lamp base.
Warning and safety
-
Use only with electromagnetic control gear
-
Lamp light technical and electrical characteristics are influenced by operating conditions, i.e. lamp ambient temperature and operating position
-
Dimming is not possible
-
A lamp breaking is extremely unlikely to have any impact on your health. If a lamp breaks, ventilate the room for 30 minutes and remove the parts, preferably with gloves. Put them in a sealed plastic bag and take it to your local waste facilities for recycling. Do not use a vacuum cleaner.
Product Data
General Information
-
Cap-Base : G24D-2 [ G24d-2]
-
Life To 10% Failures (Nom) : 6500 h
-
Life to 50% Failures (Nom) : 10000 h
-
LSF 2000 h Rated : 99 %
-
LSF 4000 h Rated : 98 %
-
LSF 6000 h Rated : 92 %
-
LSF 8000 h Rated : 78 %
Light Technical
-
Color Code : 827 [ CCT of 2700K], 830 [ CCT of 3000K], 840 [ CCT of 4000K], 865 [ CCT of 6500 K]
-
Luminous Flux (Nom) : 1200 lm
-
Luminous Flux (Rated) (Nom) : 1120 lm
-
Color Designation : Incandescent White, Warm White (WW), Cool White (CW), Cool Daylight
-
Correlated Color Temperature (Nom) : 2700 K, 3000 K, 4000 K, 6500 K
-
Luminous Efficacy (rated) (Nom) : 67 lm/W
-
Color Rendering Index (Nom) : 82
-
LLMF 2000 h Rated : 92%,92%,92%,90%
-
LLMF 4000 h Rated : 87%,87%,87%,85%
-
LLMF 6000 h Rated : 83%,83%,83%,81%
-
LLMF 8000 h Rated : 81%,81%,81%,77%
Operating and electrical
-
Power (Rated) (Nom) : 17.9 W
-
Lamp current (nom.) : 0.230 A
Temperature
-
Design temperature (nom.) : 28 °C
Control and dimming
-
Dimmable : No
Mechanical and housing
-
Cap-base infrormation : 2Pins
Approval and application
-
Mercury (Hg) content (nom.) : 1.4 mg
-
Energy consumption kWh/1,000 hours : 22 kWh
Product Data
-
Full product code : 871150062088000/871150026923200/871150064272100/871150063527300
-
Order product name : MASTER PL-C 18W/827/2P 1CT/5X10BOX, MASTER PL-C 18W/830/2P 1CT/5X10BOX, MASTER PL-C 18W/840/2P 1CT/5X10BOX, MASTER PL-C 18W/865/2P 1CT/5X10BOX
-
EAN/UPC - Product : 8711500620880/8711500269232/8711500642721/8711500635273
-
Order code : 927905782701/927905783001/927905784001/927905786502
-
Numerator - Quantity Per Pack : 1
-
Numerator - Packs per outer box : 50
-
Material Nr. (12NC) : 927905782701/927905783001/927905784001/927905786502
-
Net Weight (Piece) : 57.800 g
-
ILCOS : Code FSQ-18/27/1B-I-G24d=2, FSQ-18/30/1B-I-G24d=2, FSQ-18/40/1B-I-G24d=2, FSQ-18/65/1B-I-G24d=2
