Featuring impressive double-height dimensions, the ULTIMA PRE has been created to perfectly complement the flagship ULTIMA mono power amplifier, also the most advanced in the company’s 30-year history. With wide-ranging inputs and outputs, including balanced connectivity, the ULTIMA PRE offers complete flexibility for high-performance partnering equipment, enhanced further by the fascia-mounted separate frequency EQ adjust controls for the left and right channels. Headphone outputs offer further flexibility for late-night and personal listening in style.
Each ULTIMA PRE is hand-made in the Kent factory, with the various stages of build and production carefully overseen by one highly skilled technician. Sensitive internal circuit features are protected by solid milled aluminium shielding to prevent RF interference and Chord Electronics’ legendary UK-produced aircraft-grade aluminium provides a solid and resonance-eliminating enclosure for the electronics within, complemented by the famous Integra Leg System.
ULTIMA is the ultimate expression of the finest high-performance, ultra-fast, ultra-high-power amplifier technology available today.
Inputs & Outputs:
8 Stereo Inputs and 3 Stereo Outputs
- 4x Stereo Balanced XLR Inputs – Line In 1, Line In 2, Line In 3, and Line In 4
- 4x Stereo Unbalanced RCA Inputs – Line In 5, Line In 6, Tape 1, and Tape 2
- 3x Stereo Outputs – Selectable – Either via Balanced XLR or Unbalanced RCA
- 1x Stereo Balanced XLR AV Bypass Input
SPECIFICATIONS
Frequency response
10 Hz – 200 kHz +/- 3dB
THD
0.002 % 20 Hz – 20 kHz
Signal to noise ratio
-120dB on all inputs
Input Impedance
100 kΩ
Output impedance
100 Ω
Input maximum voltage
10 V RMS
Output maximum voltage
17 V RMS
Selectable gain
x0.5, x1, x1.5, x2, x2.5, and x3
Channel separation
100 dB
Operation voltage
80-250 V AC auto-switching
Power consumption
60 W
Dimensions Without Integra Legs:
420mm (w) x 355mm (d) x 310mm (h)
Dimensions With Included Integra Legs:
480mm (w) x 355mm (d) x 350mm (h)
Weight:
30 kg
