Features
Measure Features
Dial Depth Gauge can be used to measure depth and steps of work piece and coating thickness.
Low Measuring Force
Low measuring force type is also available, which seldom hurts work piece.
.png)
Full Specifications
| Model | Graduation (mm) | Measuring Range (mm) | Accuracy (μm) | Contact Point Form (mm) | Standard Contact Point | Measuring Force (N) | Weight (g) |
| DM-250 | 0.01 | 5 | ±10 | Needle | ZS-518 | 1.4 or less | 230 |
