Model:
DCMoto GFM-925W (Operator for swing and folding gate)
Description:
- Built In Electromagnetic Lock
- Hybrid Power Version, Reduce 95% CO² Emission
- Auto Close Timer, Intruder Alarm & Motion Lock
- Anty-Spy Wireless Multifunction Keypad & Remote Control
- Optional: Safety Beam Sensor
New DCMoto 925W Swing/Folding Type AutoGate
-----------------------------------------
DC Moto all new products are going green!
Hybrid Power; Reduces 95% CO2 emission.
A normal automatic gate consumes about 5 to 10W of electricity during standby 24/7.
The hybrid design consumes only 0.2W during standby.
Main power is only switched on for running the motor or charging the battery.
Backup battery for standby uses only 0.2 Watt.
The system will switch to normal power mode and thus function normally in case the backup battery fails.
------------------------------------------
GFM-925W-HR (Hybrid Power Version)
Specification:
- Electric motor - DC 12V
- Main power suppler - AC 230V (Hybrid Model)
- Backup battery - DV 12V 7AH
- Reduction gear with 4 stages planetary type
- Gear ration at 1:2310
- Output torque (Dynamic) - 2,000kg-cm
- Output torque (Static) - 3,240kg-cm
- Output speed (at full speed) - 1.6 r.p.m.
Package Content:
DCMOTO 925W Swing Type DC Motor x 2
DC Controller Board with PVC Box
Transformer & Backup Battery
Wireless Multifunctional Keypad
Driving Bar, Bracket & Boils
Antispy Remote Control x 3
Optional Item : Safety Beam Sensor
Auto Lock
1 YEAR WARRANTY
for more information contact Ms Angel 012-6523900
-----------------------------------------
DC Moto all new products are going green!
Hybrid Power; Reduces 95% CO2 emission.
A normal automatic gate consumes about 5 to 10W of electricity during standby 24/7.
The hybrid design consumes only 0.2W during standby.
Main power is only switched on for running the motor or charging the battery.
Backup battery for standby uses only 0.2 Watt.
The system will switch to normal power mode and thus function normally in case the backup battery fails.
------------------------------------------
GFM-925W-HR (Hybrid Power Version)
Specification:
- Electric motor - DC 12V
- Main power suppler - AC 230V (Hybrid Model)
- Backup battery - DV 12V 7AH
- Reduction gear with 4 stages planetary type
- Gear ration at 1:2310
- Output torque (Dynamic) - 2,000kg-cm
- Output torque (Static) - 3,240kg-cm
- Output speed (at full speed) - 1.6 r.p.m.
Package Content:
DCMOTO 925W Swing Type DC Motor x 2
DC Controller Board with PVC Box
Transformer & Backup Battery
Wireless Multifunctional Keypad
Driving Bar, Bracket & Boils
Antispy Remote Control x 3
Optional Item : Safety Beam Sensor
Auto Lock
1 YEAR WARRANTY
for more information contact Ms Angel 012-6523900
