PHILIPS ESSENTIAL SMARTBRIGHT SQUARE DOWNLIGHT G3 DN027B LED9/NW 6W 220-240V D100 RD 600LM

(Ø100 X 100)

Essential SmartBright LED Downlight

DN027B G3 LED20/NW 19W 220-240V D200 RD

Product Data

General Information

• Light source replaceable: No
• Number of gear units: 1 unit
• Driver included: Yes
• Lighting Technology: LED
• Inrush time: 0.115ms
• Power Consumption: 19W
• Power Factor (Fraction): 0.9
• Cable: Cable 0.2m without plug
• Number of products on MCB of 16 A type B: 55

Light Technical

• Luminous Flux: 2,100 lumen
• Correlated Color Temperature (Nom): 4000k
• Luminous Efficacy (rated) (Nom): 110.00 lm/W
• Color rendering index (CRI): 80
• Light source color: 840 neutral white
• Optic type: Beam angle 110°
• Luminaire light beam spread: 110°

Temperature

• Ambient temperature range: -20 to +40°C

Controls and Dimming

• Dimmable: No
• Driver/power unit/transformer: Power supply unit (On/Off)
• Constant light output: No]

Operating and Electrical

• Input Voltage: 220 to 240 V
• Line Frequency: 50 or 60 Hz
• Input Frequency: 50 or 60 Hz
• Inrush current: 4.92 A

Mechanical and Housing

• Housing Material: Metal - Plastic
• Reflector material: -
• Optic material: Polycarbonate
• Optical cover/lens material: Polycarbonate
• Fixation material: Steel
• Housing Color: White
• Optical cover/lens finish: Matte
• Overall length: 225mm
• Overall width: 225mm
• Overall height: 45mm
• Overall diameter: 225mm
• Dimensions (Height x Width x Depth): 45 x 225 x 225 mm

Over Time Performance (IEC Compliant)

• Driver failure rate at 5000 h: 0.012 %
• Median useful life L70B50: 30,000 hour(s)

Application Conditions

• Suitable for random switching: No

Approval and Application

• Ingress protection code: IP20/40 [Finger-protected, Emitting surface]
• Mech. impact protection code: IK03 [0.3 J]
• Protection class IEC: Safety class II
• Glow-wire test: Temperature 650°C, duration 30s
• Flammability mark: For mounting on normally flammable surfaces
• Warranty period: 3 years
• EU RoHS compliant: Yes

Initial Performance (IEC Compliant)

• Luminous flux tolerance: +/-10%
• Initial chromaticity: (IEC4000K, 0.38, 0.38) ＜ 5SDCM
• Power consumption tolerance: +/-10%

Product Data

• Full product code: 871951434522500
• Order product name: DN027B G3 LED20/NW 19W 220-240V D200 RD
• Order code: 929002674638
• Numerator - Quantity Per Pack: 1
• Numerator: Packs per outer box: 24
• Material numbeer (12NC): 929002674638
• Full product name: DN027B G3 LED20/NW 19W 220-240V D200 RD
• EAN/UPC - Case: 8719514345232
