Feature:
- – Oil lubrication contributes to long life
- – The 24l tank has sufficient air reserves
- – Applications up to 8 bar can be set using the pressure reducer
- – Pressure gauge & quick-release coupling for regulated pressure
- – Rubber wheels and carrying handle for an easy transport
- – Foot with rubber buffer for noise reduction
- – Non-return valve, safety valve
- – The drain plug enables user-friendly maintenance
Technical Data:
| Mains supply | 220-240 V | 50 Hz |
| Max. engine power (S2 | S2time) | 1500 W 2 PS 15 min |
| Engine speed | 2850 min^-1 |
| Pump speed | 2850 min^-1 |
| Suction capacity | 165 L/min |
| Output power at 0 bar | 110 L/min |
| Output power at 4 bar | 75 L/min |
| Output power at 7 bar | 55 L/min |
| Max. operating pressure | 8 bar |
| Tank volume | 24 L |
| Number of cylinders | 1 Pieces |
| Sound pressure level; Lpa | 73.4 dB (A) |
| Length | 578 mm |
| Width | 258 mm |
| Height | 572 mm |
| Gross weight single packaging | 22.68 kg |
| Product weight | 20.78 kg |
