KPN Series - High-Speed, High Accuracy Digital Process Controllers

Main features


Super high-speed sampling cycle and high display accuracy
: 50 ms sampling cycle and ±0.3% display accuracy
Large display with high luminance LED provides excellent readability
Bar graph display of control output value (MV)
High performace control (independent control outputs for heating and cooling control, automatic/manual control mode)
Parameter configuration through PCs (via USB or RS485 commmunication)
: Comprehensive device management program (DAQMaster) provided
※ Communication converters are sold separately:
: SCM-US48I (USB to RS485 converter), SCM-38I (RS232C to RS485 converter), SCM-US (USB to Serial converter)
Choose between SSR drive output or current output
Heater disconnection alarm function (CT input)
※ CT (current transformer), sold separately: CSTC-E80LN, CSTC-E200LN
Multi-SV function: configure up to 4 preset SV (by digital input terminal)
Compact, space-saving design (rear length: 60 mm)
Terminal cover, sold separately: R⃞A-COVER
Multiple input types and input range
