PARADOX
NVR780MR
– WIRELESS DUAL SIDE PIR MOTION SENSOR
Digital outdoor dual side-view detector with 4x quad sensors
NVR780MR is an WIRELESS outdoor passive infrared detectorwhich offers dual side protection with 40KG pet immunity.
It immediately trigger Paradox alarm panel via wireless data on burglar
first attempt touching windows or door from outside. NVR780MR
is easy to install because it does not need any wiring and runs on battery.
Features
- Advanced Digital Technology:
- Two double passive infrared motion detector with eight narrow detection beams, managed by Full Authority Digital Electronics Control (FADEC)
- High-resolution and full dynamic range digital signal conversion
- High-speed, advanced algorithm digital signal processing
- Digital EMI / RFI interference rejection
- True Pet Immunity, up to 40kg (90b)
- Advanced Optical Technology:
- 4x dual element sensors arrangement
- High efficiency long focal point (1.77'') lens, providing long-range narrow beams
- 2 pairs of narrow beams per side provide 2x signals per protected area crossing for increased ''catch'' and false alarm rejection
- Combination optics of mirror reflector and 2nd generation Fresnel ''LoDiff'' Lens
- Increased white light rejection
- Easy Installation and Setup:
- Single or Dual Zone operation modes: two sides can report to a single zone or to two separate zones
- Optical and digital range adjustments
- Bright LED and buzzer indicator for clear adjustment feedback
- No need for PCB removal
- Wall-mount, with built-in level tool
- In-field firmware upgradable via serial port
