rapid ‘real-time’ changes to the underlying network operation.
Brilliantly engineered with all the power you need to enable code-sending,
minus unnecessary buffer time with its distributed architecture capable of
N5400 is a high reliability, high efficiency and highly integrated intelligent
t features a 32bits Freescale ColdFire microcontroller running at 60MHz,
his control panel can fulfill most demanding requirement in physical
ACTIVE TRANSMIT
Rather than keeping the event data in the memory awaiting for host-PC to poll,
controller will actively transmits the current event data to the host server as it happens,
meaning events get delivered and can be act upon faster.
server IP can be easily done upon login. No more factory programming needed
and event storage database whenever necessary.
DOOR INTERLOCKING
2 In/Out door or 4-In doors interlocking within the control panel ,
no external wiring is needed. Cross-board interlocking is achievable by checking
the interlocking signal coming from second control panel before granting
the accessibility to the local control panel.
Feature Highlight
~ Support Single Doors / 2 Doors / 4-In doors
~ Support Car Park Mode
~ Support Dynamic Reader Location
~ Compatible with Various Reader Technologies
~ ActiveTransmit & ActiveDownload
~ Peer To Peer Global Anti-Passback
~ Configurable Digital / Supervised Inputs (8)
~ Event Based Triggering (EBT)
~ Unlimited Access Level
~ Onboard & Cross-Board Interlocking
~ User Counting (Card Holder / Car Park)
~ Advance Encryption Standard (AES)
~ Reader Output Control
~ Dynamic Storage Allocation
~ Dynamic Operation Profile
~ Support 30,000 Users And 80,000 Events Memory
| Technical Specification | |
| Hardware | Description |
| Dimension | 158mm (w) x 90mm (H) |
| MCU | 32bits @ 60MHz |
| Memory |
256K Flash Memory 32K SRAM (Buffer) 64Mbits Non-Volatile SPI Flash Memory (Storage) |
| Operating Temperature | 0 °C to 40 °C |
| Card Holder | 30,000 |
| Event Transaction | 80,000 |
| Access Level | Unlimited Access Level |
| Digital/Supervise Inputs |
Max 8, User configurable (Door Sensor/Request-To-Exit/Fire Input/General Purpose) |
| Digital Output | Max. 4 Dry contact Relay |
| Network Communication Port | RJ-45 Self-Negotiate 10/100mbps |
| Power Protection | Resettable Fuse - 2.5A |
| Surge Protection | TVS - Up to 15KVA |
| Onboard LED Control | Power / Communication / LAN / Event / Error |
| AC Fail Monitoring | Yes |
| Battery Monitoring | Yes (Firmware threshold control to shutdown control panel) |
| External Short Circuit Protection | At readers |
| Backup Battery | Yes, Apply to RTC only |
